Urban Arrow, Family Cargo

$11,999.00 $9,499.00

Urban Arrow Family Cargo



Meet the aptly named Family: the newest member of your tribe. One that takes you and your most precious cargo wherever you want to go. The bike's speed and agility will be more than a match for your hectic lifestyle. Our range of accessories will allow you to customize it to meet your family's needs. Leave the car at home and zip through the city effortlessly, or enjoy a trip to the woods or the beach. One ride, and you'll be hooked!


Turn rush hour into fun hour

The light frame, electric pedal assist, stepless gear shifting and low point of gravity guarantee a very pleasant riding experience. It is cycling the way you already know, plus agility, stability and safety. And with the wide range of accessories, you can tune your bike to match your family’s needs. Your Urban Arrow will be so versatile that you might find yourself leaving that car on the driveway. And there’s always a cherry on top: no more traffic!


Efficient, integrated power source

Bosch's lithium-ion batteries are among the most advanced on the market. Their intelligent battery management system guarantees a long life, while the efficient energy control optimizes your bike's range. With the integrated PowerPack 500Wh battery, you'll always have enough range. The battery is secured in the frame with a lock. You can easily remove it from the bike with a key that also works on the café lock. Convenient, as you can charge the battery either on or off the bike.

Discover new places with Bosch's quiet yet powerful motor

The Bosch Cargo Line Gen 4 gives you everything your cyclist's heart desires. Smooth and powerful assistance that will never let you down; 20mph max assisted speed;  you can handle any terrain.

Safety & Security

The Urban Arrow Cargo Line prioritizes safety without sacrificing convenience. Featuring high-quality Schwalbe tires, hydraulic disc brakes, and an aluminum steering rod, you’ll have precise control and superior stopping power in any weather. The bike’s integrated Bosch GPS module ensures anti-theft tracking and includes an alarm system, so you'll always know where your bike is, even from halfway around the world.

Pedal system

Confidently zig-zag your way through traffic. The light frame, electric pedal assistance and stepless gear shifting guarantee a very pleasant riding experience. It is cycling the way you are used to, with agility and comfortable stability.


Safe and Sound

With a huge front load capacity of 125 kg (275 lbs), the bike includes dual three-point safety harnesses, perfect for securely transporting your children. And with accessories like the Raincover Plus, Baby Seat Adapter, and Cargo Net, you can customize your Urban Arrow to fit your needs now and into the future.

The lowered children’ seating position makes for an overall lower center of gravity. This has a positive effect on the way in which the Family adheres to the road. A sturdy and adjustable three-point belt provides safety during the ride. And the expanded polypropylene (EPP) box protects your most precious cargo all around.






All specifications

51kg
260cm
70cm
110cm
250kg
125kg
125kg


Bike Specification

Frame Alloy
Fork UA rigid fork
Wheels Front: Ryde Andra 40 Double wall 20" x 1.75
Rear: Ryde Andra 29 SB Black 26"
Hubs Front: Shimano HB-M525A, 36H
Rear: Enviolo Cargo, 36H
Spokes Front: Sapim spokes (14G)
Rear: Sapim spokes (13G)
Tires Schwalbe Super Moto
Crankset Miranda Delta 0, ISIS
Shifters Enviolo TR - Trekking
Rear Derailleur Enviolo Cargo Internal Geared Hub
Chain KMC X1 Silver 100L
Brakes Magura CMe5
Brake Levers Shimano Zee
Handlebars Ergotec Moon cruiser 31.8 black
Tape/Grips Ergon GC10
Stem TranzX JD-ST17-2 black 1-1/8 25.4 110mm
Seatpost Promax custom seatpost & clamp w/groove
Saddle Selle Royal Rio Plus
Pedals C558
Accessories & Extras Lezyne E115
Motor Bosch Cargo Line Gen 4; 20mph max assisted speed; 25 – 50 miles range
Battery Bosch 500Wh
Controller/Display Bosch Intuvia
Charger 4 amp







QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question
Delivered Assembled to Lower Mainland Vancouver customers
