Urban Arrow FamilyNext Front Loading Electric Cargo Bike (Pre-Order)
DESCRIPTION
Road's Next Icon, Urban Arrow FamilyNext
The FamilyNext Pro from Urban Arrow is full packed with some of the most amazing advancements in electric bike technology. It is built to the highest standard, so you can enjoy a premium bike feel, the spacious cargo, and the stability brought by the low center of gravity in the design. This is a redefined version of their Family model, so you can expect an even smoother, more spacious, and more comfortable ride.
Best Features:
- Bosch Motor and Battery - never go wrong with a reputable brand!
- Three-point Seatbelt - enjoyable and safer ride
- 125 kg Capacity - handle more with the frontload box
- Suntour Front Suspension Fork - experience maximum comfort
- New Colorway - a green variant is added to the Family models

What makes Urban Arrow's FamilyNext Pro stand out?
Best Features

Bosch PowerPack Battery
The PowerPack is ideal for extra-long rides and eBikes with high energy requirements.

One-Handed 3-Point Seatbelt System
This offers convenience as it is ideal for easy and secure child loading

Best-in-Class Load Capacity
550 lbs total (275 lbs front box)

Front Suspension Fork
Equipped in the bike for smooth, stable rides on city streets and trails

Integrated LED Lights
This is designed to be in the box for enhanced visibility

Everything in one glance
Equipped with the Bosch LED remote and Kiox 300
EXPLORE THE ANATOMY OF URBAN ARROW FAMILYNEXT PRO
COMPARISON SHEET
Bosch Cargo Line Gen 4 BES3, 250W - max 85 Nm
Bosch PowerPack 545W
250 kg
Gates Carbon Belt Drive CDX 120
Bosch LED Remote + KIOX 30
Rear tire: Schwalbe Super Moto X 62-559
Front tire: Schwalbe Super Moto X 62-406
Rear rim: Ryde Andra 29 26"
Front rim: Ryde Andra 40 20"
Front hub, UA 110x15 Thru axle Cargo
UA4.5, aluminium
Color: Black or Green
Material: EPP Foam
Suspension fork, Suntour Mobie34 CGO Boost, 20", 60mm
Eco, Tour, Sport, Turbo
Enviolo Twist Display pro
Rear brake: Magura CMe, 8.S Pads
Brake rotor rear: Magura 203mm MDR-C
Adapter rear: Magura QM44 PM180-203
Front brake: Magura CMe, 8.S Pads
Brake rotor front: Magura 180mm MDR-C
Ergotec Moon cruiser 31.8mm
Selle Royal Rio Plus with handle
Rear light: Spanninga Plateo XE 6V-36V
Front light: Lezyne Power E115
UA seatpost with groove 31,6m
Ergotec Integra Octopus
Miranda Delta 0 , Gen 4
FamilyNext Pro in Action
a closer look on how it blends into your life

Ditch The Car — Bring Everyone Along

Safely Hit The Road

Shared Rides to Shared Stories
ALL URBAN ARROW
COMPARISON SHEET
Find which Family Model is suitable for your needs
Bosch Cargo Line Gen 4, 250W - max. 85 Nm
Bosch Cargo Line Gen 4 BES3, 250W - max 85 Nm
Battery Bosch
Bosch PowerPack 545W
250 kg
250 kg
Chain, KMC X1 Silver 100L
Gates Carbon Belt Drive CDX 120
Bosch Intuvia
Bosch LED Remote + KIOX 30
Rear tire: Schwalbe Big Ben Plus 55-559
Front tire: Schwalbe Big Ben Plus 55-406
Rear tire: Schwalbe Super Moto X 62-559
Front tire: Schwalbe Super Moto X 62-406
Rear rim: Ryde Andra 40 Double wall 26" x 1.75; Sapim spokes (13G)
Front rim: Ryde Andra 40 Double wall 20" x 1.75; Sapim spokes (14G)
Rear rim: Ryde Andra 29 26"
Front rim: Ryde Andra 40 20"
Rear hub, internal gear Enviolo Cargo, 36H
Front hub, UA 110x15 Thru axle Cargo
UA4.2, aluminium
Color: Black or White
UA4.5, aluminium
Color: Black or Green
Material: EPP Foam
Material: EPP Foam
UA rigid fork
Suspension fork, Suntour Mobie34 CGO Boost, 20", 60mm
Eco, Tour, Sport, Turbo
Eco, Tour, Sport, Turbo
Enviolo TR - Trekking
Enviolo Twist Display pro
Rear brake: Magura Cme Lever right w banjo, 2200mm hose
Brake rotor rear: Magura MDR-C 203mm
Rear brake: Magura CMe, 8.S Pads
Brake rotor rear: Magura 203mm MDR-C
Adapter rear: Magura QM44 PM180-203
Front brake: Magura CMe, 8.S Pads
Brake rotor front: Magura 180mm MDR-C
Ergotec Moon cruiser 25,4 black
Ergotec Moon cruiser 31.8mm
Selle Royal Rio Plus
Selle Royal Rio Plus with handle
Rear light: Spanninga Plateo XE 6V-36V
Front light: Lezyne Power E115, 1520mm cable
Rear light: Spanninga Plateo XE 6V-36V
Front light: Lezyne Power E115
Satori Trident 31,6 400mm Black
UA seatpost with groove 31,6m
TranzX JD-ST17-2 black 1-1/8 25,4 110mm
Ergotec Integra Octopus
Miranda Delta 0 , ISIS
Miranda Delta 0 , Gen 4
A front-loader cargo, also known as 'bakfiet', is an e-bike with a cargo space between handlebar and the front wheel. This cargo bike has low center of gravity, which balances the bike and gives the rider ease in switching directions.
With a front-loader cargo e-bike, the rider can keep their eye on their cargo space, which weighs twice as much as a regular e-bike can carry.
The battery options ranges from 400Wh to 800Wh, but it may vary depending on usage. You have the choice to double the range of your cargo bike with the double battery set option that the design allows.
The FamilyNext Cargo E-Bike from Urban Arrow can carry up to 4 children (3 in the front and 1 on the rear) or haul a total payload of 250 kg. The children or your luggages are totally safe since the cargo e-bike is equipped with a 3-point seatbelt and a high-quality cargo box made out of expanded polypropylene (EPP).
There can be confusion regarding this, so let us help clear things up. There is a sticker labeling that the maximum capacity is 36kg, which refers to the seatbelt capacity based on conducted test.
The maximum weight that the seat/bench of Urban Arrow FamilyNext can hold is up to 100 kg.
The Urban Arrow FamilyNext is the most spacious and sleekest UA yet. They offer ultimate comfort with innovative features intended for safety such as:
- Integrated suspension fork
- Box redesigned for ease in mounting
- A very comfortable saddle
- New fabric for harness
- Black spokes
- Reflective designs all over the bike
- Enhanced LED lights
- Higher backrest
The Urban Arrow FamilyNext is 110 cm tall.
The Urban Arrow FamilyNext is 260 cm long.
An electric cargo bike is an eBike with a cargo space situated in either the rear or front end. It has a high hauling and carrying capacity meant for boarding passengers or loading groceries.
An electric cargo bike can have a total payload of 250kg or more. This includes the bike, the rider, and the cargo.
Yes. An electric cargo bike has the capacity to carry children in terms of weight. However, it is important to use the integrated safety features or accessories to ensure that your children is safety during the ride.
Not really, but a beginner can find it unusual at first. Although, the electric assist makes pedaling easier and it offsets the amount of weight. It is also designed to have low center of gravity, making it very stable. A few rides can help you learn how to handle a lengthier bike.
Absolutely! Smaller families can greatly benefit to an electric bike with an impeccable capacity that can carry 1-4 kids. It can make school trips, groceries, and leisure so much easier and cheaper. It is a very sustainable option that also serves a useful function.
An electric cargo bike is lengthier or heavier than standard design of hitch racks, so it may be difficult to load it on a car. However, you may be able to do it on special cases like loading it on a pick-up truck or a customized hitch rack.
